Caret service
Read and position the caret in the current editing view. Use it to place inserted content or restore a visible authoring position.
The facade is available as editor.Caret; its interface can be replaced by an application implementation.
Use it in your application
Text indices are UTF-16 units in the API-defined current view. They are not positions in an encoded HTML file or interchangeable with legacy MSHTML ranges.
All examples assume an editor named editor, already attached to a visible window, and an awaited editor.Ready. Keep operations asynchronous instead of blocking the UI thread.
await editor.Caret.SetCaretAtEndAsync();
int index = await editor.Caret.GetCaretIndexAsync();
Members
These declarations come from the package's own XML documentation. Await operations and supply cancellation tokens where your application needs them.
GetCaretBoundsAsync Method
Returns the actual document-relative caret rectangle in DIP units, or null when unrealized.
Syntax
Task<Rect?> GetCaretBoundsAsync(CancellationToken cancellationToken = default)
GetCaretIndexAsync Method
Returns the actual current-view UTF-16 caret index, or -1 when unavailable.
Syntax
Task<int> GetCaretIndexAsync(CancellationToken cancellationToken = default)
GetCaretIndexInHtmlAsync Method
Returns a safely mapped body-markup UTF-16 index in the rendered document, or the visible draft index in source mode; -1 indicates unavailable mapping.
Syntax
Task<int> GetCaretIndexInHtmlAsync(CancellationToken cancellationToken = default)
GetCaretPositionAsync Method
Returns the actual document-relative caret location, or null when no caret geometry is available.
Syntax
Task<Point?> GetCaretPositionAsync(CancellationToken cancellationToken = default)
HideAsync Method
Hides the actual caret without moving it or changing content.
Syntax
Task HideAsync(CancellationToken cancellationToken = default)
ScrollToCaretViewAsync Method
Reveals the actual caret without changing its offset or the document.
Syntax
Task ScrollToCaretViewAsync(CancellationToken cancellationToken = default)
SetCaretAtAsync Method
Places the caret at a finite document point in DIP coordinates, optionally revealing it.
Syntax
Task SetCaretAtAsync(double x, double y, bool scrollToView = true, CancellationToken cancellationToken = default)
SetCaretAtEndAsync Method
Moves to the end of the actual current-view document.
Syntax
Task SetCaretAtEndAsync(CancellationToken cancellationToken = default)
SetCaretAtHomeAsync Method
Moves to the start of the actual current-view document.
Syntax
Task SetCaretAtHomeAsync(CancellationToken cancellationToken = default)
SetCaretAtLineBeginningAsync Method
Moves to the beginning of the caret's current visual line, honoring wrapping.
Syntax
Task SetCaretAtLineBeginningAsync(CancellationToken cancellationToken = default)
SetCaretAtLineEndAsync Method
Moves to the end of the caret's current visual line, honoring wrapping.
Syntax
Task SetCaretAtLineEndAsync(CancellationToken cancellationToken = default)
SetCaretByIndexAsync Method
Collapses the current-view selection at a bounded UTF-16 offset.
Syntax
Task SetCaretByIndexAsync(int index, CancellationToken cancellationToken = default)
Selects a bounded current-view UTF-16 range without editing the document or draft.
Syntax
Task SetCaretByIndexAsync(int index, int length, CancellationToken cancellationToken = default)
SetCaretPositionAsync Method
Places the caret at the same document point as SetCaretAtAsync.
Syntax
Task SetCaretPositionAsync(double x, double y, bool scrollToView = true, CancellationToken cancellationToken = default)
ShowAsync Method
Shows the actual caret, optionally scrolling it into the current viewport.
Syntax
Task ShowAsync(bool scrollToView = true, CancellationToken cancellationToken = default)
